Paper Dunnage Bag BDB-1016 100x160 cm

Stowage Bag for Cargo Protection BDB1016

The durable stowage bag is used to secure shipments during transportation. It is an inexpensive and highly effective way for the safe transport of cargo. Air bags are easy to use. The time required to inflate is only a few dozen seconds.

Why Choose Stowage Bags?

1. Low Cost
Thanks to the low price of the bags and their negligible weight, you effectively reduce transportation costs. Moreover, the bags can be reused.

2. Environmentally Friendly
The durable materials used for the production of the bags allow them to be reused and are also recyclable.

3. Effective Cargo Protection
The large surface area of the stowage bags perfectly distributes the forces acting on the transported products.
They effectively absorb vibrations, prevent packages from shifting, and help avoid tipping over.

4. Storage
Before the air bag is inflated, it is flat and light, which makes storage convenient.

5. Easy to Use
To inflate the packages, a simple ball pump or compressor with an appropriate nozzle is sufficient.

6. Wide Range of Sizes
There are 22 combinations of bag sizes available – so you can secure cargoes of various dimensions. The smallest bag measures 50x50cm, while the largest is as big as 120x240cm!

Applications of Stowage Cushions

The safety of the transported cargo is one of the key issues in transportation. Damage to the entrusted goods may result in the operation becoming unprofitable or even expose the company to financial losses!
Stowage bags are an excellent option for protecting packages transported in vans, trailers, containers, trains, etc. The cushions should be placed in empty spaces and then inflated.
When properly used, the bags:
- fill empty spaces
- prevent packages from moving around in the cargo area
- protect against tipping (e.g. refrigerators)
- fill the gaps between goods, preventing them from colliding with each other

Properties of Stowage Bags:
- structure that allows perfect adaptation to adjacent items
- made from high-quality raw materials
- reusable (capable of being inflated and deflated)
- when not inflated, they take up little space
- resistant to moisture and weather conditions
- an ideal solution for securing cargo during transport
- can be inflated with a hand pump or compressor with a dedicated nozzle
- possesses excellent damping properties
- environmentally friendly product, reusable or recyclable
- puncture resistant
- construction material: outer layer—packaging paper laminated on PE fabric, 70g/m2; inner layer: multi-layer coextruded PA+PE foil with a special formula, the coextruded foil thickness is 75um.
- height: 1000mm
- width: 1600mm
- working pressure: 20kPa / 0.2 bar / 2.8 PSI
- maximum pressure 3.0 PSI
- maximum gap size fillable: 20cm
- suitable for use in vans, trailers, containers, warehouses, maritime, air, and rail transport.

Wide Range of Sizes

Choosing the appropriate bag size for your cargo is key to its safety. In the table above, 22 possible bag size combinations are highlighted in blue.

Convenient Inflation System for the Stowage Bag

Thanks to the new Inflate & Deflate system, the bag can be easily inflated and deflated as needed. The valve is equipped with a stopper that prevents air from escaping on its own. An additional plug ensures the set’s tightness. Another advantage is the attached handle, which makes it easier to hold the cushion during inflation. After transport, the air can be quickly released by unscrewing the stopper, and the bag can be used again if needed!

Inflating the bag is just a few simple steps:
1. Remove the black safety plug
2. Attach the appropriate nozzle to the pump or compressor
3. Grab the handle, press the nozzle to the valve, and inflate the bag
4. The air can be released from the cushion by unscrewing the stopper.

How to Use Stowage Bags?

For the cushions to perform their function, they must be placed in relation to the transported cargo. The diagram above shows examples of incorrect and proper use of the cushions. There is no golden rule and each transport requires an individual approach as well as the application of various solutions.

You can also find in our offer bags dedicated to other items and objects.
There is also the possibility of producing bags tailored to your product according to depth, length, height or
height and diameter.


Declaration of Conformity
https://spacetronik.eu/katalogi/banery/deklaracja-zgodnosci-worki-sztauerskie.pdf
