Paper Dunnage Bag BDB-0812 80x120 cm

Loading Bag for Cargo Protection BDB0812

The durable loading bag is used to secure shipments during transport. It is an inexpensive and extremely effective way to safely transport cargo. The air bags are easy to use. The time needed to inflate is only a few dozen seconds.

Why Choose Loading Bags?

1. Low Cost
Thanks to the low price of the bags and their negligible weight, you can effectively reduce transportation costs. Moreover, the bags can be reused.

2. Environmentally Friendly
The durable materials used in the production of the bags allow them to be used repeatedly and are also recyclable.

3. Effective Cargo Protection
The large surface area of the loading bags perfectly distributes the forces acting on the transported products.
They effectively absorb vibrations, prevent packages from shifting, and guard against tipping over.

4. Storage
Before the air bag is inflated, it is flat and light, which makes for convenient storage.

5. Easy to Use
To inflate the packages, a simple ball pump or a compressor with the appropriate nozzle is sufficient.

6. Wide Range of Sizes
There are 22 size combinations available, which means that loads of various dimensions can be protected. The smallest bag measures: 50x50cm, and the largest as much as 120x240cm!

Applications of Loading Cushions

The safety of the transported cargo is one of the key issues in transportation. Damage to the entrusted goods may result in the trip becoming unprofitable or even expose the company to financial losses!
Loading bags are an excellent option that works well in protecting packages transported in vans, trailers, containers, trains, etc. The cushions should be placed in empty spaces and then inflated.
If used correctly, the bags:
- fill empty spaces
- prevent the packages from shifting within the cargo area
- protect against tipping over (e.g., refrigerators)
- fill the spaces between goods so that they do not bump against each other

Properties of the Loading Bags:
- structure that allows for an ideal fit to the items placed beside them
- made of high quality raw materials
- reusable (ability to inflate and deflate)
- when not inflated, they take up little space
- resistant to moisture and weather conditions
- the ideal solution for securing cargo during transport
- can be inflated with a hand pump or a compressor with a dedicated nozzle
- possesses excellent cushioning properties
- environmentally friendly product, capable of being reused or recycled
- puncture resistant
- material: outer layer – packaging paper laminated on a PE fabric, grammage 70g/m2; inner layer is a multi-layer co-extruded PA+PE film with a special formula, the thickness of the co-extruded film is 75um.
- height: 800mm
- width: 1200mm
- operating pressure: 20kPa / 0.2 bar / 2.8 PSI
- maximum pressure 3.0 PSI
- maximum gap size that can be filled: 20cm
- used in vans, trailers, containers, warehouses, sea, air and rail transport.

Wide Range of Sizes

Choosing the appropriate size bag for the cargo is key to its safety. In the table above, 22 possible size combinations of the bags are highlighted in blue.

Convenient System for Inflating the Loading Bag

Thanks to the new Inflate & Deflate system, the bag can be easily inflated and deflated when needed. The plug is equipped with a valve that prevents air from escaping on its own. An additional protection is offered by a cap that ensures the set’s tightness. Another plus is the built-in handle, which makes it easier to hold the cushion during inflation. After the transport is finished, the air can be quickly let out by unscrewing the plug, and then it can be reused if necessary!

Inflating the bag is just a few simple steps:
1. Remove the black safety cap
2. Attach the appropriate nozzle to the pump or compressor
3. Grab the handle, place the nozzle on the valve and inflate the bag
4. The air can be released by unscrewing the plug.

How to Use Loading Bags?

For the cushions to serve their purpose, they must be arranged relative to the transported cargo. The diagram above shows examples of both incorrect and correct use of the cushions. There is no golden rule and each transport requires an individual approach and the application of different solutions.

Our offer also includes bags dedicated to other items and objects.
It is also possible to produce bags tailored to your product according to its depth, length, height or
height and diameter.
