Paper Dunnage Bag BDB-0612 60x120 cm

Tie-Down Air Bag for Cargo Protection BDB0612

The durable tie-down air bag is used to secure shipments during transportation. This is an inexpensive and extremely effective method for safely transporting cargo. Air bags are easy to use. The time needed for inflation is only a few dozen seconds.

Why Choose Tie-Down Air Bags?

1. Low cost
Thanks to the low price of the bags and their negligible weight, you effectively reduce transport costs. Moreover, the bags can be reused.

2. Environmentally friendly
The durable materials used for production allow the bags to be reused multiple times and are also recyclable.

3. Effective cargo protection
The large surface area of the tie-down air bags evenly distributes the forces acting on the transported products.
They effectively absorb vibrations, protect against packages shifting, and prevent overturning.

4. Storage
Before the air bag is inflated, it is flat and light, which allows for convenient storage.

5. Easy to use
For inflating the packaging, a regular ball pump or compressor with an appropriate nozzle is sufficient.

6. Wide range of sizes
There are 22 combinations of bag sizes available – this allows you to secure cargo of various dimensions. The smallest bag measures: 50x100cm, and the largest is as big as 120x240cm!

Applications for Tie-Down Air Bags

The safety of the transported cargo is one of the key issues in transportation. Damage to the entrusted goods may result in the route becoming unprofitable or even exposing the company to financial losses!
Tie-down air bags are an excellent option that will be effective in protecting packages transported in vans, trailers, containers, trains, etc. The air bags should be placed in empty spaces and then inflated.
Properly used air bags:
- fill empty spaces
- prevent packages from shifting within the cargo space
- protect against overturning (e.g. refrigerators)
- fill gaps between goods, thus preventing them from colliding with each other

Features of Tie-Down Air Bags:
- structure allowing perfect adaptation to the items placed next to each other
- made from high-quality raw materials
- reusable (capable of being inflated and deflated)
- when uninflated, they take up little space
- resistant to moisture and weather conditions
- the ideal solution for securing cargo during transportation
- can be inflated using a hand pump or a compressor with a dedicated nozzle
- has excellent cushioning properties
- environmentally friendly product, reusable or recyclable
- puncture resistant
- material: outer layer - wrapping paper laminated on PE fabric, weight 70g/m2; inner multi-layered layer - coextruded PA+PE film with a special formula, the thickness of the coextruded film is 75um.
- height: 600mm
- width: 1200mm
- working pressure: 20kPa / 0.2 bar / 2.8 PSI
- maximum pressure 3.0 PSI
- maximum gap size that can be filled: 20cm
- intended for use in vans, trailers, containers, warehouses, maritime, air, and rail transport.

Wide Range of Sizes

Selecting the appropriate bag size for the cargo is the key to its safety. In the table above, 22 possible combinations of bag sizes are highlighted in blue.

Convenient Inflation System for the Tie-Down Air Bag

Thanks to the new Inflate & Deflate system, the bag can be easily inflated and deflated when necessary. The plug is equipped with a valve that prevents air from escaping on its own. Additional protection is provided by a stopper that guarantees the seal of the set. Another advantage is the built-in handle that makes it easier to hold the bag while inflating. After the transport is finished, the air can be quickly released by unscrewing the plug, and then, if necessary, the bag can be used again!

Inflating the bag is just a few simple steps:
1. Remove the black safety stopper
2. Attach the appropriate nozzle to the pump or compressor
3. Grab the handle, position the nozzle to the valve, and inflate the bag
4. The air in the bag can be released by unscrewing the plug.

How to Use Tie-Down Air Bags?

For the air bags to perform their function, they must be arranged relative to the transported cargo. The diagram above shows examples of improper and proper use of the air bags. There is no golden rule, and every transport requires an individual approach and the application of various solutions.

Our offer also includes bags dedicated to other items and objects.
It is also possible to produce bags customized to your product according to depth, length, height or
height and diameter.

Declaration of Conformity: https://spacetronik.eu/katalogi/banery/deklaracja-zgodnosci-worki-sztauerskie.pdf
